Ranger TRE-2627

General characteristics

HAM bands

11m (CB)

Frequency stability

0.003% (-30 to +50 °C)

Tuning steps

?

Memories

?

Receiver

RX-range

26.965-27.405 MHz

Modulations

AM   USB   LSB

Sensitivity

AM: 0.5 µV (10 dB S/N)
SSB: 0.25 µV (10 dB S/N)

Selectivity

60 dB (adjacent channel)

Filters

?

Receiver system

Single conversion (SSB) / double conversion (AM) superheterodyne

IF-frequencies

10.695 MHz / 455 kHz

Image rejection

50 dB

Audio output

2.5 W (8 ohm, 10% THD)

Transmitter

TX-range

26.965-27.405 MHz

Modulations

AM   USB   LSB

RF-output

AM: 4 W, SSB: 12 W PEP

Connections

Antenna

SO-239

Impedance

50Ω

Other

-

Electrical

Power requirements

110-120 V AC or 13.8 V DC

Current drain RX

0.5-1 A (13.8 V DC)

TX

3.5 A max (13.8 V DC)

Physical

Dimensions (w×h×d)

286 × 121 × 343 mm (11.26 × 4.76 × 13.50 in)

Weight

5.44 kg (12.0 lbs)

Form factor

Base Station

Manufactured

Between 2025 and 20xx in Malaysia

Other features

Usage

Citizen Band (27Mc)

Features + options

40 channels
S/RF/SWR/modulation meter
Channel 9/19 switch
PA
Roger beep
ANL/NB
Galaxy noise filter (GNF)
Dimmer

Accessories

-

RigReference ID

6692

MPN

RANGER-TRE-002627
