Quansheng UV-K10 Pro
Amateur Handheld Transceiver
Add a review (+10 rep) Own this rig? Add it to your shack
Normal receive range is 30-580 MHz. With the optional Si4732 module it receives 0.153-580 MHz, adding LW, MW and SW. GPS positioning is also optional. The official page does not say whether SSB/CW receive needs the Si4732 module.
Transmit power is given as ≤10 W with H/M/L selection; the individual power levels are not specified.
Modulation: 11K0F3E (12.5 kHz) / 16K0F3E (25 kHz). Max. deviation ≤5 kHz (25 kHz) / ≤2.5 kHz (12.5 kHz).
Spurious emission ≤7.5 µW. Adjacent channel power 70 dB (25 kHz) / 60 dB (12.5 kHz). Modulation distortion ≤5%. Residual modulation 40 dB. Audio distortion ≤10%.
Broadcast memories: FM 32, LW 32, MW 32, SW 18.
Keys: 19 on the front, 3 function keys and PTT on the left side. Operating temperature: -20 to +60 °C.
Other functions: Chinese/English channel names, custom power-on picture, emergency alarm, power-on password, remote kill/revive, DTMF ANI and select call, busy channel lock, repeater forwarding confirmation.
See also Quansheng UV-K5.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ±1 ppm
- Tuning steps
- ?
- Memories
- 999 channels in bank(s)
Receiver
- RX-range
- 30-580 MHz
0.153-580 MHz with optional Si4732 module - Modulations
- AM FM N-FM W-FM CW SSB
- Sensitivity
- FM (12 dB SINAD): -121 dBm (18-76, 108-136, 174-350, 470-580 MHz), -123 dBm (136-174, 350-470 MHz)
W-FM (20 dB SINAD): -110 dBm (76-108 MHz)
AM (10 dB S/N): -100 dBm (0.153-1.8 MHz), -110 dBm (1.8-30 MHz), -113 dBm (108-136 MHz) - Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ≥0.5 W
Transmitter
- TX-range
- 136-174 / 350-490 MHz
- Modulations
- FM N-FM
- RF-output
- ≤10 W (H / M / L)
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- USB-C for charging (radio body and battery)
Electrical
- Power requirements
- 7.4 V, 2500 mAh polymer Li-ion battery USB-C charging on the radio or the battery, or charging base
- Current drain RX
- ?
- TX
- ≤2.5 A
Physical
- Dimensions (w×h×d)
- 54.9 × 107.9 × 36.7 mm (2.16 × 4.25 × 1.44 in) without knob
- Weight
- 271 gr (9.6 oz) without antenna and belt clip
- Form factor
- Handheld
- Manufactured
- Between 2026 and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Receive 30-580 MHz; 0.153-580 MHz with optional Si4732 (LW/MW/SW)
Dual-band transmit 136-174 / 350-490 MHz, H/M/L power
FM/AM/SSB/CW receive
Optional GPS / APRS
Bluetooth app programming, PC programmable
Spectrum analyzer, frequency meter, field strength display
1.44" RGB display, adjustable colour
999 channels, dual standby
NOAA weather (10 ch)
Wireless radio copy, one-key frequency matching
DTMF, 5-tone, 1750 Hz, CTCSS/DCS, VOX, scrambler
USB-C charging on radio and battery - Accessories
- Battery, charging cable, adaptor, belt clip, antenna, hand strap
- RigReference ID
- 6854
- MPN
- QUANSHENG-UV-K000010-PRO
