General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz
Memories
100 channels in 1 bank(s)

Receiver

RX-range
118-174 MHz
Modulations
AM   FM   N-FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM   N-FM
RF-output
High: 50 W, Medium: 10 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
142 × 40 × 174 mm (5.59 × 1.57 × 6.85 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 199x and 2000

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS, DCS. GPS input for APRS. 1200/9600 bd packet (EJ-41U) and digital voice board options (requires at least two similarly equipped radios)
Accessories
-
RigReference ID
2312
MPN
ALINCO-DR-000135E

Manuals, diagrams and brochures

Alinco DR-135/435MK3 FXE Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DR-135/235/435 Service manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-135E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Alinco DR-135E is around:

  • EUR 114.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2013 EUR 159.00 Used / Good thiecom.de
