General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
100 channels in 1 bank(s)

Receiver

RX-range
350-512 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
430-450 MHz
Modulations
FM
RF-output
High: 35 W, Medium: 10 W, Low: 5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
11.7-15.8V DC
Current drain RX
400-600 mA
TX
Max 10 A

Physical

Dimensions (w×h×d)
142 × 40 × 174 mm (5.59 × 1.57 × 6.85 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 2001 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
1K2/9K6 TNC option, GPS input for APRS. CTCSS, DCS. Theft alarm. 20F3 DV option (requires at least two similarly equipped radios)
Accessories
-
RigReference ID
2325
MPN
ALINCO-DR-000435T
