New price 1991 in the US: $619.95

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?

Receiver

RX-range
132-170 / 410-470 MHz
Modulations
FM
Sensitivity
-16dB micro (0.16µv) or less (12 dB SINAD)
Selectivity
-6 dB: 6 kHz min., -60 dB: 12 kHz max.
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
.5 watts (8 ohm load) @ 5% distortion

Transmitter

TX-range
144-148 / 440-450 MHz
Modulations
FM
RF-output
High: 45/35 W, Mid: 10/8W, Low: 5/4 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
1.2A max
TX
10A max

Physical

Manufactured
Between 199x and 199x
Dimensions (w×h×d)
150 × 50 × 178 mm (5.91 × 1.97 × 7.01 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile

Other features

Memories
28 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
Detachable head. Twin RX
Accessories
?
MPN
ALINCO-DR-000590T

Manuals, diagrams and brochures

Alinco DR-590 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DR-590 Service manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-590T. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
