General characteristics

HAM bands
10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
28-29.7 MHz
Modulations
FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
60 dB
Audio output
?

Transmitter

TX-range
28-29.7 MHz
Modulations
FM
RF-output
High: 5 W, Low: 0.5 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
6.3-16V DC
Current drain RX
28-150 mA
TX
0.5-1 A

Physical

Dimensions (w×h×d)
60 × 174 × 33 mm (2.36 × 6.85 × 1.30 in)
Weight
550 gr (1.2 lbs)
Form factor
Handheld
Manufactured
Between 200x and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2416
MPN
AZDEN-AZ-000011
