General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
20 channels in 1 bank(s)

Receiver

RX-range
118-174 MHz
Modulations
AM   FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
High: 50 W, Low: 10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 0.6 A
TX
?

Physical

Dimensions (w×h×d)
139.7 × 50.8 × 184.15 mm (5.50 × 2.00 × 7.25 in)
Weight
1.40 kg (3.1 lbs)
Form factor
Mobile
Manufactured
Between 1991 and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS
Accessories
-
RigReference ID
2428
MPN
AZDEN-PCS-006000H

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Azden PCS-6000H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Azden PCS-6000H is around:

  • USD 4.00 ~ USD 49.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 USD 50.00 Used / Good Dave
1991 USD 259.00 New / Mint N6OTQ
