Uniden-Bearcat BC220FB

Desktop VHF/UHF Scanner / receiver

View all reviews (0) Add a review Add to my shack



Login or Register to upload images

Find Uniden-Bearcat BC220FB rigs and spare parts on eBay Find the Uniden-Bearcat BC220FB on Amazon
We receive a small fee when you buy through these links, thank you!

Made by the Electra Company

Frequency range

RX-range
66-88 / 118-136 / 144-174 / 420-512 MHz
TX-range
-
HAM bands
?
Stability
?
Tuning steps
5 kHz
Filters
?

Receiver

Modulations
AM   FM
Sensitivity
VHF AM: 1 µV (10 dB S/N)
VHF FM: 0.4 µV (12 dB SINAD)
UHF: 0.8 µV (12 dB SINAD)
Selectivity
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.8 MHz
2nd: 400 KHz
Image rejection
?
Audio output
?

Transmitter

Modulations
-
RF-Output
?

Connections

Antenna
TV-antenne
Impedance
50/75 Ω

Electrical

Power requirements
13.8V DC or mains
Current drain RX
550-770 mA @ 13.8 VDC
TX
-

Physical

Dimensions (w×h×d)
265 × 75 × 195 mm (10.43 × 2.95 × 7.68 in)
Weight
2.40 kg (5.3 lbs)
Form factor
Base Station
Manufactured
Between 1979 and 198x in USA
MPN
UNIDEN-BEARCAT-BC000220FB

Other features

Memories
20 channels in 4 bank(s) @ 11 channels/second
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
