General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 12.5 kHz

Receiver

RX-range
68-88 / 108-174 /380-512 MHz
Modulations
AM   FM
Sensitivity
0.5 µV
Selectivity
+/-10 kHz (-6 dB), +/-18kHz (-50 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.7 MHz
2nd: 455 KHz
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
12V DC
Current drain RX
?
TX
-

Physical

Manufactured
Between 200x and 200x
Dimensions (w×h×d)
210 × 52 × 175 mm (8.27 × 2.05 × 6.89 in)
Weight
?
Form factor
Unknown

Other features

Memories
200 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
GRE-/-GRECOM-PSR-000220
