General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 12.5 / 25 / 50 kHz

Receiver

RX-range
25-1300 MHz
Modulations
AM   FM   W-FM
Sensitivity
AM/FM
25-1000 MHz: 0.5 µV
1000-1300 MHz: 3 µV
W-FM
25-1000 MHz: 3 µV
1000-1300 MHz: 15 µV
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 225.4125 MHz
2nd: 45 MHz
3rd: 455 KHz
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 500 mA
TX
-

Physical

Manufactured
Between 200x and 200x
Dimensions (w×h×d)
232 × 90 × 210 mm (9.13 × 3.54 × 8.27 in)
Weight
2.00 kg (4.4 lbs)
Form factor
Unknown

Other features

Memories
500 channels in 10 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
GRE-/-GRECOM-PSR-000225
