Early Lamb crystal filter without selectivity control

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
0.2-10 MHz
Modulations
AM   CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
-
Impedance
200 Ω
Other
-

Electrical

Power requirements
Separate PSU
Current drain RX
Max 80 W
TX
-

Physical

Manufactured
Between 1937 and 19xx
Dimensions (w×h×d)
455 × 261 × 440 mm (17.91 × 10.28 × 17.32 in)
Weight
14.00 kg (30.9 lbs)
Form factor
Base Station

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
HAMMARLUND-SP-000110LX
