General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 12.5 kHz

Receiver

RX-range
68-88 / 144-174 / 410-512 MHz
Modulations
FM
Sensitivity
VHF: 1 µV, UHF: 2 µV (20 dB S/N)
Selectivity
18 kHz (-6 dB), 34 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
TV-antenne
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-15V DC or mains
Current drain RX
?
TX
-

Physical

Manufactured
Between 197x and 198x in Japan
Dimensions (w×h×d)
260 × 80 × 270 mm (10.24 × 3.15 × 10.63 in)
Weight
2.40 kg (5.3 lbs)
Form factor
Base Station

Other features

Memories
8 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
HANDIC-000012

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Handic 0012. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices: (see all 0 prices)
