General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
68-88 / 144-174 MHz
Modulations
FM
Sensitivity
1.0 µV
Selectivity
13.5 kHz (-6 dB)
20 kHz (-60 dB)
Filters
?
Receiver system
Crystal controlled double conversion
IF-frequencies
1st: 10.7 MHz
2nd: 455 kHz
Image rejection
35 dB
Audio output
2 W into 8 ohms

Connections

Antenna
KOK1 (Motorola)
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
12-15 V DC
Current drain RX
10 W
TX
-

Physical

Manufactured
Between 1974 and 1986
Dimensions (w×h×d)
115 × 45 × 165 mm (4.53 × 1.77 × 6.50 in)
Weight
?
Form factor
Mobile

Other features

Memories
8 channels in 1 bank(s) @ 20 channels/second
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
HANDIC-000006-(NEWER)

Manuals, diagrams and brochures

Handic 006 Owner's Manual submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Handic 006 (Newer). Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Handic 006 (Newer) is around:

  • EUR 0.00

These estimates are based on the following prices: (see all 1 prices)

Year Historic price Condition Submitted by
1993 EUR 20.00 Used / Good pienari
