General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
143.5-148.5 MHz
Modulations
FM
Sensitivity
± 0.15 µV for 12 dB SINAD
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
Requires external speaker

Transmitter

TX-range
143.5-148.5 MHz
Modulations
FM
RF-output
10 W

Connections

Antenna
RCA (Tulip)
Impedance
50 Ω
Other
-

Electrical

Power requirements
12.6-16 V DC (HWA-2036-3 Power Supply)
Current drain RX
0.7 A
TX
2.6 A max

Physical

Dimensions (w×h×d)
210 × 70 × 249 mm (8.27 × 2.76 × 9.80 in)
Weight
3.20 kg (7.1 lbs)
Form factor
Mobile
Manufactured
Between 197x and 197x in USA (late seventies)

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2925
MPN
HEATHKIT-HW-002036

Manuals, diagrams and brochures

Heathkit HW-2036 assembly manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit HW-2036. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Heathkit HW-2036 is around:

  • USD 17.00 ~ USD 13.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2013 USD 284.00 Used / Mint eBay
2013 USD 41.00 Used / Okay eBay
2013 USD 32.00 Used / Okay eBay
2013 USD 39.00 Used / Okay eBay
2013 USD 19.00 Used / Fair eBay
