ICOM IC-202E Handheld VHF Transceiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack

Image wanted!



Frequency range

RX-range
144-146 MHz
TX-range
144-146 MHz
HAM bands
-
Stability
-
Tuning steps
-
Filters
-

Receiver

Modulations
CW   SSB
Sensitivity
-
Selectivity
-
Receiver system
-
IF-frequencies
-
Image rejection
-
Audio output
-

Transmitter

Modulations
CW   SSB
RF-Output
3 W

Connections

Antenna
Built-in sweep
Impedance
50 Ω

Electrical

Power requirements
13.8V DC
Current drain RX
90-250 mA
TX
750 mA

Physical

Dimensions (w×h×d)
61 × 183 × 162 mm (2.40 × 7.20 × 6.38 in)
Weight
2.00 kg (4.4 lbs)
Form factor
Handheld
Manufactured
Between 1977 and 19xx
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
Features + options
VXO
Accessories
-

Manuals, diagrams and brochures

ICOM IC-202 Schematic Diagram-3.gif submitted by RigReference
ICOM IC-202 Schematic Diagram-2.gif submitted by RigReference
ICOM IC-202 Schematic Diagram-1.gif submitted by RigReference
ICOM IC-202 Schematic Diagram-4.gif submitted by RigReference
