General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
212 channels in 1 bank(s)

Receiver

RX-range
118-899.9875 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 50/35 W, Medium: ?/? W, Low: 5/5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1.8 A
TX
Max 12 A

Physical

Dimensions (w×h×d)
140 × 50 × 270 mm (5.51 × 1.97 × 10.63 in)
Weight
1.40 kg (3.1 lbs)
Form factor
Mobile
Manufactured
Between 2002 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS & DTCS. 9k6 packet ready. Twin RX
Accessories
-
RigReference ID
3031
MPN
ICOM-IC-002725E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-2725E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-2725E is around:

  • EUR 106.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2012 EUR 175.00 Used / Good ahaifisch
