General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
12.5 / 25 kHz
Memories
20 channels in 1 bank(s)

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
N-FM
Sensitivity
< 0.25 µV for 12 dB SINAD
Selectivity
?
Filters
?
Receiver system
Double-conversion superheterodyne
IF-frequencies
1st: 30.875 MHz
2nd: 455 kHz
Image rejection
?
Audio output
> 400 mW at 10 % distortion with an 8 Ω load

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
N-FM
RF-output
High: 5.5/5 W, Low: 1/1 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
7.2-13.2 V DC battery pack or 12-15 V DC external
Current drain RX
10-250 mA
TX
2.2 A max

Physical

Dimensions (w×h×d)
65 × 159 × 35 mm (2.56 × 6.26 × 1.38 in) with BP-3
Weight
510 gr (1.1 lbs) with BP-3
Form factor
Handheld
Manufactured
Between 1988 and 199x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3072
MPN
ICOM-IC-000032E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-32E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-32E is around:

  • EUR 270.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 EUR 300.00 New / Mint Ruediger
