General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
220-225 MHz
Modulations
FM
Sensitivity
Less than 0.2 µV for 12 dB SINAD
Selectivity
More than 15 kHz (-6 dB), less than 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
220-225 MHz
Modulations
FM
RF-output
High: 25 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.5-0.7 A
TX
3-6.5 A

Physical

Dimensions (w×h×d)
140 × 38 × 177 mm (5.51 × 1.50 × 6.97 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Unknown
Manufactured
Between 198x and 198x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3082
MPN
ICOM-IC-000037A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-37A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:
