General characteristics

HAM bands
70cm
Frequency stability
?
Tuning steps
?
Memories
4 channels in 1 bank(s)

Receiver

RX-range
430-440 MHz
Modulations
FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
430-440 MHz
Modulations
FM   CW   SSB
RF-output
High: 10 W, Low: 1 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
Max 3.6 A

Physical

Dimensions (w×h×d)
170 × 64 × 218 mm (6.69 × 2.52 × 8.58 in)
Weight
2.60 kg (5.7 lbs)
Form factor
Mobile
Manufactured
Between 198x and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Dual VFO's. Scanning
Accessories
-
RigReference ID
3103
MPN
ICOM-IC-000490A
