General characteristics
- HAM bands
- 6m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 3 channels in 1 bank(s)
Receiver
- RX-range
- 50-54 MHz
- Modulations
- FM CW USB LSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 50-54 MHz
- Modulations
- FM CW USB LSB
- RF-output
- High: 10 W, Low: 1 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- ?
- TX
- 3.5 A max
Physical
- Dimensions (w×h×d)
- ?
- Weight
- ?
- Form factor
- Mobile
- Manufactured
- Between 197x and 198x in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Memories scan
Band scan
Variable shifts
RIT
NB
Digital display
Analog S-meter - Accessories
- -
- RigReference ID
- 3120
- MPN
- ICOM-IC-000560
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-560. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
These estimates are based on the following prices:
