General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.1-30 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   SSB
RF-output
10-100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
424 × 150 × 390 mm (16.69 × 5.91 × 15.35 in)
Weight
?
Form factor
Base Station
Manufactured
Between 1987 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Built-in auto-AT. RS-232C
Accessories
-
RigReference ID
3166
MPN
ICOM-IC-000761
