General characteristics

HAM bands
2m
Frequency stability
± 10 p.p.m. (-10°C to +60°C)
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz
Memories
207 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
Modulations
FM   AFSK
Sensitivity
Less than 0.15 µV for 12 dB SINAD
Selectivity
More than 6/3 kHz at -6 dB, Less than 14/9 kHz at -60 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st 21.7 MHz
2nd 450 kHz
Image rejection
75 dB
Audio output
More than 2 W at 10% distortion with an 8 load

Transmitter

TX-range
144-146 MHz (Asia)
144-148 MHz (USA)
Modulations
FM   AFSK
RF-output
5 / 10 / 25 / 75 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC +/-15% (negative ground)
Current drain RX
0.3-1 A
TX
15 A max

Physical

Dimensions (w×h×d)
150 × 50 × 150 mm (5.91 × 1.97 × 5.91 in)
Weight
1.10 kg (2.4 lbs)
Form factor
Mobile
Manufactured
Between 2002 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Selectable green or amber display. CTCSS and DCS. Standard DTMF encoder and optional decoder. Weather alert scan (US version only).
Accessories
-
RigReference ID
3257
MPN
ICOM-IC-V008000

Manuals, diagrams and brochures

ICOM IC-V8000 receive expand mods PDF - Unknown size, submitted by RigReference
ICOM IC-V8000 service manual PDF - Unknown size, submitted by RigReference
ICOM IC-V8000 instruction manual PDF - Unknown size, submitted by RigReference
ICOM IC-V8000 optional instruction manual PDF - Unknown size, submitted by RigReference
ICOM IC-V8000 expanding function PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Almost 75 Watts 15 years ago by NE3R

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-V8000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-V8000 is around:

  • EUR 196.00
  • USD 142.00 ~ USD 25.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 EUR 200.00 Used / Mint pe1owg
2020 USD 149.00 Used / Good eBay
2012 USD 100.00 Used / Good Rodgerzk
2005 USD 189.99 Used / Good NE3R
2003 USD 200.00 New / Mint n0nab
