QQE03/12 final . New price 1970 in West Germany: DM 1148.-

General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
AM   FM   CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
AM   FM
RF-output
Max 8 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
12V DC or mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
300 × 160 × 340 mm (11.81 × 6.30 × 13.39 in)
Weight
6.00 kg (13.2 lbs)
Form factor
Base Station
Manufactured
Between 1970 and 197x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
IF-mechanical filter, squelch, noise limiter.
Accessories
-
RigReference ID
3577
MPN
MINIX-MTR-000025S
