New price 1965 in West Germany: 995.- DM

General characteristics

HAM bands
80m  60m  40m  20m  15m  10m
Frequency stability
< 100 cps for 10% line fluctuation after warm up
Tuning steps
Continuous

Receiver

RX-range
10-80 m
Modulations
AM   FM   CW   SSB
Sensitivity
0.5 µV (10 dB S/N)
Selectivity
SSB: 2.1 kHz @ -6 dB, 2.5 kHz @ -60 kHz
AM: 4 kHz @ -6 dB, 7.5 kHz @ -25 kHz
AM: 2.1 kHz @ -6 dB, 2.5 kHz @ -25 kHz
CW: 5 kHz @ -6 dB, 2.5 kHz @ -60 kHz
Filters
?
Receiver system
Single conversion superheterodyne
IF-frequencies
455 kHz
Image rejection
> 50 dB
Audio output
2 W

Connections

Antenna
SO-239
Impedance
50/70Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
50 W
TX
-

Physical

Manufactured
Between 1965 and 196x
Dimensions (w×h×d)
380 × 180 × 330 mm (14.96 × 7.09 × 12.99 in)
Weight
12.00 kg (26.5 lbs)
Form factor
Base Station

Other features

Memories
None
Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
MPN
SOMMERKAMP-FR-000100B

Manuals, diagrams and brochures

Yaesu FR-100b Schematic Diagram-01.gif submitted by RigReference
Yaesu FR-100b Schematic Diagram-02.gif submitted by RigReference
Sommerkamp FR100B Instruction book submitted by RigReference
