4 crystal-controlled memory positions.

General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
Continuous
Memories
4 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz in four 500 kHz segments
Modulations
FM   CW   USB   LSB
Sensitivity
SSB/CW: 0.5 µV (10 dB S/N)
FM: -4 dBV (20 dB QS)
Selectivity
SSB/CW: 2.4 kHz (-6 dB), 4.1 kHz (-60 dB)
FM: 15 kHz (-6 dB), 25 kHz (-60 dB)
Filters
?
Receiver system
Single (SSB/CW) / double (FM) conversion superheterodyne
IF-frequencies
1st: 10.7 MHz
2nd: 455 kHz
Image rejection
60 dB
Audio output
2 W at 10% distortion / 4 ohms

Transmitter

TX-range
144-146 MHz in four 500 kHz segments
Modulations
FM   CW   USB   LSB
RF-output
FM/CW: 10 W, SSB: 10 W PEP

Connections

Antenna
SO-239
Impedance
50-75Ω
Other
-

Electrical

Power requirements
12-14.5 V DC or mains
Current drain RX
600 mA
TX
3 A max

Physical

Dimensions (w×h×d)
280 × 125 × 295 mm (11.02 × 4.92 × 11.61 in)
Weight
8.50 kg (18.8 lbs)
Form factor
Unknown
Manufactured
Between 1974 and 197x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
VOX
NB
100 kHz calibrator
Repeater tone burst 1300-3000 Hz adjustable
Accessories
-
RigReference ID
3977
MPN
SOMMERKAMP-FT-000220

Manuals, diagrams and brochures

Sommerkamp FT-220 Schematic Diagram PDF - 1.05 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Sommerkamp FT-220. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Sommerkamp FT-220 is around:

  • EUR 66.00
  • USD 104.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 105.00 Used / Okay eBay
2016 EUR 70.00 Used / Fair earman
