General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
10-80 m
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Tubes
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
Modulations
CW   SSB
RF-Output
SSB: 560 W (PEP input), CW: 500 W (input)

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Manufactured
Between 1971 and 1973 in Japan
Dimensions (w×h×d)
400 × 159 × 350 mm (15.75 × 6.26 × 13.78 in)
Weight
18.15 kg (40.0 lbs)
Form factor
Base Station

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
SOMMERKAMP-FTDX-000505

Manuals, diagrams and brochures

Yaesu FTdx-505 Instruction Manual submitted by RigReference
Yaesu-FT-401 / FTdx-505 Circuit diagram (01) submitted by RigReference
Yaesu-FT-401 / FTdx-505 Circuit diagram (02) submitted by RigReference
Yaesu-FT-401 / FTdx-505 Circuit diagram (03) submitted by RigReference
Yaesu-FT-401 / FTdx-505 Circuit diagram (04) submitted by RigReference
Yaesu-FT-401 / FTdx-505 Circuit diagram (05) submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Sommerkamp FTdx-505. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices: (see all 0 prices)

Year Historic price Condition Submitted by
