General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
12.5 kHz

Receiver

RX-range
144-147.9875 MHz (320 channels)
Modulations
FM
Sensitivity
1 µV (25 dB SINAD)
Selectivity
7.5 kHz (-6 dB)
Filters
?
Receiver system
? conversion superheterodyne
IF-frequencies
?
Image rejection
Better than 60 dB
Audio output
?

Transmitter

TX-range
144-147.9875 MHz (320 channels)
Modulations
FM
RF-Output
High: 45 W (100% duty cycle!), Low: 5 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
10-16V DC
Current drain RX
300 mA
TX
Max 8 A

Physical

Manufactured
Between 197x and 1980 in Japan
Dimensions (w×h×d)
156 × 58 × 290 mm (6.14 × 2.28 × 11.42 in)
Weight
2.30 kg (5.1 lbs)
Form factor
Mobile

Other features

Memories
320 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
SOMMERKAMP-TS-000280FM-(US-VERSION)
