General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
Continuous

Receiver

RX-range
0.53-30 / 88-108 MHz
Modulations
AM   W-FM   CW   SSB
Sensitivity
AM (A3) 1,3 - 2 μV
SSB 0,3 - 0,6 μV
Selectivity
3,1/7,8 kHz, 4,8/xx kHz (WA) resp. 4,5 kHz/ 9 kHz (W) (-6/-46 dB)
Filters
-
Receiver system
Double conversion superheterodyne
IF-frequencies
AM: 19,055 MHz / 455 kHz
FM: 10,7 MHz
Image rejection
?
Audio output
?

Connections

Antenna
Clamps / screws + Built-in ferrite bar + Built-in sweep
Impedance
?
Other
-

Electrical

Power requirements
Mains or 6 × LR20/UM-1
Current drain RX
?
TX
-

Physical

Manufactured
Between 1980 and 1983 in Japan
Dimensions (w×h×d)
457 × 190 × 235 mm (17.99 × 7.48 × 9.25 in)
Weight
5.44 kg (12.0 lbs)
Form factor
Portable

Other features

Memories
None
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
SONY-ICF-006800W
