The Central Electronics 200V was unique for its time, it requires no tuning of the final or other controls to use (broadband tuning). It has a built in 2" oscilloscope for monitoring various functions. It had two sets of set and forget controls on the front panel, behind two drop down doors. It has a PTO inside, and a drum dial with fine vernier type tuning. Other features include VOX and PTT.

The band coverage was wider than strictly the ham bands. Each band covered 1 MHz, with (per the manual) "Generous coverage outside the ham bands". Actual coverage was:
3.5-4.5 MHz
6.5-7.5 MHz
13.5-14.5 MHz
20.5-21.5 MHz
27.5-30.5 MHz
An optional 160 m kit could also be fitted plus there was the capability of adding a 1 MHz range anywhere in the HF range.

General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Transmitter

TX-range
80-10 m with 160 m option
Modulations
AM   CW   SSB   DSB   FSK   RTTY
RF-output
100 W (180 W INPUT)

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
-
TX
?

Physical

Dimensions (w×h×d)
457 × 222 × 381 mm (17.99 × 8.74 × 15.00 in)
Weight
40.80 kg (90.0 lbs)
Form factor
Base Station
Manufactured
Between 196x and 196x

Other features

Usage
Amateur / Ham radio operators
Features + options
2" oscilloscope
Accessories
-
RigReference ID
5054
MPN
CENTRAL-ELECTRONICS-000200V
