Philips RT-2000 Portable Shortwave Transceiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

The RT-2000 (also known as PRC-2000) was built in Great Britain by M.E.L. / Philips. It is a fully transistorized radio for portable and vehicle use from the late 80s. It was used in the Falkland War; improvements suggested there were built in later. The RT-2000 shares the footprint with the Philips RT-3600 and units can be stacked together.

Frequency range

RX-range
1.6-30 MHz
TX-range
1.6-30 MHz
HAM bands
-
Stability
-
Tuning steps
0.1 kHz
Filters
-

Receiver

Modulations
CW   USB   LSB   FSK
Sensitivity
0.6 µV @ 10dB
Selectivity
-
Receiver system
-
IF-frequencies
-
Image rejection
-
Audio output
150 mW @ 75 Ohm; 2 W @ 4 Ohm external loudspeaker

Transmitter

Modulations
CW   USB   LSB   FSK
RF-Output
4/20 W

Connections

Antenna
BNC + Proprietary (military)
Impedance
50Ω

Electrical

Power requirements
10-32 V DC
Current drain RX
3 W
TX
60 W

Physical

Dimensions (w×h×d)
-
Weight
-
Form factor
Portable
Manufactured
Between 198x and 199x in Netherlands / UK by Philips / M.E.L.
MPN

Other features

Memories
10 channels in 1 bank(s)
Usage
Military communication
Features + options
Operational range: 30 ... 50 km
Watertight: 1 hour at 1 meter
CPU controlled
Built-in antenna tuner (ATU)
Speech processor
