The Kenwood TM-2550A is a mobile VHF transceiver. It covers 144-148 MHz for both receive and transmit. The receiver system is double conversion superheterodyne with IF frequencies of 1st: 10.695 MHz, 2nd: 455 kHz. RF output is 5-45 W. Audio output is > 1.5 W across 8 ohm with 5% distortion. It requires 13.8 V DC power supply. Current drain is 600 mA in receive and 9.5 A in transmit. Dimensions are 60 × 180 × 215 mm.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ± 15 p.p.m.
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 144-148 MHz
- Modulations
- FM
- Sensitivity
- < 0.25 µV (12 dB SINAD)
- Selectivity
- 12 kHz (-6 dB)
24 kHz (-60 dB) - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 10.695 MHz
2nd: 455 kHz - Image rejection
- ?
- Audio output
- > 1.5 W across 8 ohm with 5% distortion
Transmitter
- TX-range
- 144-148 MHz
- Modulations
- FM
- RF-output
- 5-45 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC
- Current drain RX
- 600 mA
- TX
- 9.5 A
Physical
- Dimensions (w×h×d)
- 180 × 60 × 215 mm (7.09 × 2.36 × 8.46 in)
- Weight
- 1.95 kg (4.3 lbs)
- Form factor
- Mobile
- Manufactured
- Between 198x and 198x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- DCL
- Accessories
- -
- RigReference ID
- 5446
- MPN
- KENWOOD-TM-002550A
Manuals, diagrams and brochures
- TM-2550A E PDF - 25.12 MB, submitted by Berend
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TM-2550A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Kenwood TM-2550A in Good condition is around:
- USD 147
These estimates are based on the following prices:
