Military R209

Mobile Shortwave receiver

View all reviews (0) Add a review Add to my shack



Login or Register to upload images

Frequency range

RX-range
1-20 MHz in 5 bands
TX-range
-
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
AM   FM   CW
Sensitivity
?
Selectivity
?
Receiver system
Superhet with RF-stage
IF-frequencies
460 kHz
Image rejection
?
Audio output
0.05 W

Transmitter

Modulations
-
RF-Output
?

Connections

Antenna
Proprietary (military)
Impedance
50Ω

Electrical

Power requirements
12 / 24 V DC, 110 / 120 V AC depending on version
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
310 × 215 × 230 mm (12.20 × 8.46 × 9.06 in)
Weight
10.50 kg (23.2 lbs)
Form factor
Mobile
Manufactured
Between 1951 and 197x
MPN
MILITARY-R000209

Other features

Memories
?
Usage
Military communication
Features + options
?
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Military R209 user manuals on eBay

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Military R209. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Military R209 is around:

  • EUR 19.00
Year Historic price Condition Submitted by
2010 EUR 40.00 Used / Okay elmer
