Mobile Transcan version

General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
8 channels in 1 bank(s) @ 15 channels/second

Receiver

RX-range
144-148 MHz
Modulations
FM
Sensitivity
0.35 µV
Selectivity
16 kHz @ -6 dB
32 kHz @ -50 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
10.7 MHz / 455 kHz
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
15 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.6 V DC
Current drain RX
380-800 mA
TX
2.9 A

Physical

Dimensions (w×h×d)
102 × 254 × 216 mm (4.02 × 10.00 × 8.50 in)
Weight
?
Form factor
Mobile
Manufactured
Between 197x and 197x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5974
MPN
REGENCY-HR-000002MS
