General characteristics

HAM bands
6m  2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 kHz
Memories
999 channels in 1 bank(s)

Receiver

RX-range
FM: 26-30 / 50-54 / 65-108 / 108-181 / 320-350 / 400-480 / 700-988 MHz
AM: 108-136 MHz
Modulations
AM   FM   N-FM
Sensitivity
0.25 µV (13 dB SINAD)
700-998 MHz: -97 dBm (13 dB SINAD)
Selectivity
12.5 kHz < -60 dB
25 kHz < -70 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
≥ 70 dB
Audio output
3 W

Transmitter

TX-range
26-30 / 50-54 / 136-175 / 400-480 MHz
Modulations
FM   N-FM
RF-output
5-50 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC ±15%
Current drain RX
500 mA
TX
9 A max

Physical

Dimensions (w×h×d)
140 × 44 × 207 mm (5.51 × 1.73 × 8.15 in)
Weight
1.44 kg (3.2 lbs)
Form factor
Mobile
Manufactured
Between 2013 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
DTMF-mic
Dual display
Detachable front panel
Called ID
Twin RX
Cross-band repeater
Accessories
-
RigReference ID
6020
MPN
WOUXUN-KG-UV000950P(L)
