General characteristics

HAM bands
20m  17m (WARC)  15m
Frequency stability
?
Tuning steps
?
Memories
10 channels in 1 bank(s)

Receiver

RX-range
13.9-22 MHz
Modulations
CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
IF-DDS: 60 MHz
Image rejection
?
Audio output
?

Transmitter

TX-range
14.0-14.3 / 18.068-18.168 / 21.0-21.45 MHz
Modulations
CW
RF-output
4-5 W @ 13.8 V

Connections

Antenna
BNC
Impedance
?
Other
-

Electrical

Power requirements
9-16 V DC
Current drain RX
120-130 mA
TX
800 mA

Physical

Dimensions (w×h×d)
120 × 51 × 103 mm (4.72 × 2.01 × 4.06 in)
Weight
420 gr (14.8 oz)
Form factor
Mobile
Manufactured
Between 2013 and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
Built-in keyer
Accessories
-
RigReference ID
6031
MPN
YOUKITS-EK-000001B

Manuals, diagrams and brochures

Youkids EK1B Schematic PDF - 26.4 kB, submitted by RigReference
Youkids EK1B User Manual PDF - 766.9 kB, submitted by RigReference
Youkids EB1B Assembly Manual PDF - 2.51 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Youkits EK-1B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Youkits EK-1B is around:

  • EUR 107.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 EUR 150.00 New / Mint marcnl
