Heathkit SB-614 Monitoring Scope

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

This is the solid-state replacement of the Heathkit SB-610. RF-input power 10-300 and 10-1000 Watts.

Frequency range

RX-range
3.5-54 MHz
TX-range
-
HAM bands
80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Stability
-
Tuning steps
-
Filters
-

Receiver

Modulations
All mode
Sensitivity
60 mV / 1/4" deflection (horizontal and vertical)
Selectivity
-
Receiver system
-
IF-frequencies
-
Image rejection
-
Audio output
-

Transmitter

Modulations
All mode
RF-Output
-

Connections

Antenna
SO-239
Impedance
50Ω

Electrical

Power requirements
Mains (120-240 V AC)
Current drain RX
25 W
TX
-

Physical

Dimensions (w×h×d)
-
Weight
-
Form factor
Base Station
Manufactured
Between 1974 and 197x in USA
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
