The Eddystone 710, also known as the All-World Six, was developed for battery operated use. It had low current consumption of only 2.5 A from a 6 volt accumulator. The required high voltage was derived from a vibrator and no high tension battery was required.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
500 kHz - 30.6 MHz in 5 bands
Modulations
AM   CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Superheterodyne
IF-frequencies
450 kHz
Image rejection
?
Audio output
1 W

Connections

Antenna
-
Impedance
70Ω
Other
-

Electrical

Power requirements
Batteries
Current drain RX
2.5 A
TX
-

Physical

Manufactured
Between 1949 and 195x in Great Britain
Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station

Other features

Memories
?
Usage
Marine / Navy
Features + options
Automatic volume control
Accessories
?
MPN
EDDYSTONE-000710
