This model is sold as the DR-B185HE or DR-B185HT for the European and North-American markets respectively.

General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 / 6.25 / 8.33 / 10 / 12.5 kHz
Memories
500 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
Modulations
FM   N-FM
Sensitivity
0.25 µV
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 45.1 MHz
2nd: 450 kHz
Image rejection
65 dB
Audio output
2 W at 10% distortion / 8 ohms

Transmitter

TX-range
144-146 MHz
Modulations
FM   N-FM
RF-output
5 / 85 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC ±15%
Current drain RX
1 A
TX
20 A max

Physical

Dimensions (w×h×d)
164 × 44 × 184 mm (6.46 × 1.73 × 7.24 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile
Manufactured
Between 2015 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS / PL
DCS
2-tone
DTMF
Accessories
-
RigReference ID
6384
MPN
ALINCO-DR-B000185

Manuals, diagrams and brochures

Alinco DR-B185HT/HE User Manual PDF - 2.33 MB, submitted by RigReference
