The Alinco DR-635T is a mobile VHF/UHF transceiver. It covers 87.5-108 / 108-174 / 335-480 MHz for reception and 144-148 / 430-450 MHz for transmission. The receiver system is a double conversion superheterodyne with IF frequencies of 1st: 21.7 MHz / 450 kHz, 2nd: 45.1 MHz / 455 kHz. RF output power is High: 50/35 W, Medium: 20/20 W, Low: 5/5 W. The audio output is 2W into 8 ohm @ 10% THD. It features 1 memory bank with 202 channels. Dimensions are 40 × 140 × 185 mm. Weight is 1 kg. Current drain is 500-700 mA (RX) and Max 11 A (TX).
General characteristics
- HAM bands
- 2m
- Frequency stability
- +/- 2.5 p.p.m.
- Tuning steps
- ?
- Memories
- 202 channels in 1 bank(s)
Receiver
- RX-range
- 87.5-108 / 108-174 / 335-480 MHz
- Modulations
- AM FM N-FM W-FM
- Sensitivity
- Main band: 0.2 µV or better (12 dB SINAD)
Sub band: 0.25 µV or better (12 dB SINAD) - Selectivity
- 12 kHz (-6 dB), 28 kHz (-60 dB)
- Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 21.7 MHz / 450 kHz
2nd: 45.1 MHz / 455 kHz - Image rejection
- ?
- Audio output
- 2W into 8 ohm @ 10% THD
Transmitter
- TX-range
- 144-148 / 430-450 MHz
- Modulations
- FM N-FM
- RF-output
- High: 50/35 W, Medium: 20/20 W, Low: 5/5 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC +/- 15%
- Current drain RX
- 500-700 mA
- TX
- Max 11 A
Physical
- Dimensions (w×h×d)
- 140 × 40 × 185 mm (5.51 × 1.57 × 7.28 in)
- Weight
- 1,000 gr (2.2 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2005 and 200x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Detachable control head. Theft alarm. CTCSS & DCS. Twin RX. 1200/9600 bd packet and GPS option (EJ-50U). 10F3 digital voice board (EJ-47U) option (requires at least two similarly equipped radios)
- Accessories
- -
- RigReference ID
- 2338
- MPN
- ALINCO-DR-000635T
