Introductory price 2001 in the US: $379.95

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 7.5 / 10 / 12.5 / 20 / 25 / 50 / 100 kHz
Memories
500 channels in 10 bank(s) @ 100 channels/second

Receiver

RX-range
25-512 / 806-956 / 1240-1300 MHz (cellular blocked in the US)
Modulations
AM   FM   W-FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
2 W

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 700 mA
TX
-

Physical

Dimensions (w×h×d)
176 × 61 × 167 mm (6.93 × 2.40 × 6.57 in)
Weight
1.33 kg (2.9 lbs)
Form factor
Mobile
Manufactured
Between 2000 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Trunktracker III, tracks Motorola, EDACS and LTR systems
SAME w/FIPS
CTCSS / DCS
PC programmable
Alpha tags
Rotary control
Recorder control
Data skip
Auto store
Beep alert
Accessories
-
RigReference ID
2453
MPN
UNIDEN-BEARCAT-BC000780XLT

Manuals, diagrams and brochures

Uniden BC780 Programming Control Codes (v. 1.04) PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Uniden-Bearcat BC780XLT. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Uniden-Bearcat BC780XLT is around:

  • EUR 137.00
  • USD 12.00 ~ USD 2.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 EUR 140.00 Used / Good SWL_de
2010 USD 75.00 Used / Good R1VINCE
2006 USD 100.00 Used / Good R1VINCE
2004 USD 50.00 Used / Good R1VINCE
2001 USD 200.00 Used / Good R1VINCE
