General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
12 channels in 1 bank(s)

Receiver

RX-range
146-148 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
146-148 MHz
Modulations
FM
RF-output
1.5 W

Connections

Antenna
Built-in telescopic
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
30-75 mA
TX
Max 445 mA

Physical

Dimensions (w×h×d)
138 × 58 × 216 mm (5.43 × 2.28 × 8.50 in)
Weight
2.00 kg (4.4 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2602
MPN
DRAKE-TR-000033C

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Drake TR-33C. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:
