General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 / 1 / 0.1 kHz
Memories
3 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz
Modulations
FM   CW   SSB
Sensitivity
SSB/CW: Better than 0.5 µV (10 dB S+N/N)
FM: Better than 0.6 µV for 20 dB noise quieting
Selectivity
SSB/CW: 2.4 kHz (-6 dB), 4.8 kHz (-60 dB)
FM: 15 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
More than 60 dB
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM   CW   SSB
RF-output
1-10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
Max 0.6 A
TX
Max 2.3 A

Physical

Dimensions (w×h×d)
241 × 111 × 264 mm (9.49 × 4.37 × 10.39 in)
Weight
5.00 kg (11.0 lbs)
Form factor
Base Station
Manufactured
Between 1980 and 198x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3015
MPN
ICOM-IC-000251E

Manuals, diagrams and brochures

Icom IC-251 Schematic Diagram PDF - 574.5 kB, submitted by Mike
Amateur Radio Magazine July 1983 PDF - 8.32 MB, submitted by Mike
Icom IC-251 A/E Instruction Manual PDF - 7.20 MB, submitted by Mike

Upload relevant documents

Reviews & stories

Rating Title Submitted
Icom IC-251E 4 years ago by flick_nife

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-251E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-251E is around:

  • EUR 298.00
  • GBP 0.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 EUR 300.00 New / Mint IW3HZS
2010 GBP 0.00 Used / Mint flick_nife
