General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.1-30 MHz
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   CW   SSB
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
900 mA
TX
Max 20 A

Physical

Dimensions (w×h×d)
241 × 111 × 311 mm (9.49 × 4.37 × 12.24 in)
Weight
7.50 kg (16.5 lbs)
Form factor
Base Station
Manufactured
Between 1980 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3136
MPN
ICOM-IC-000720

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
super 720a 14 years ago by jonah12

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-720. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-720 is around:

  • GBP 40.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 GBP 250.00 Used / Mint jonah12
