Kenwood TR-2200A

Mobile VHF Transceiver

Specs Manuals (1) Reviews (0) Prices (0) Compare

Find Kenwood TR-2200A rigs and spare parts on eBay

The Kenwood TR-2200A is a mobile VHF transceiver. It covers 146-148 MHz for both receive and transmit. The radio has a maximum RF output of 2 W on high power and 400 mW on low power. It features 1 memory bank with 12 channels. Dimensions are 58 × 135 × 181 mm.

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: ?
Memories: 12 channels in 1 bank(s)

Receiver

RX-range: 146-148 MHz
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: XTAL
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 146-148 MHz
Modulations: FM
RF-output: High: 2 W, Low: 400 mW

Connections

Antenna: Built-in sweep
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 12V DC
Current drain RX: ?
TX: ?

Physical

Dimensions (w×h×d): 135 × 58 × 181 mm (5.31 × 2.28 × 7.13 in)
Weight: ?
Form factor: Mobile
Manufactured: Between 197x and 197x in Japan

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 3441
MPN: KENWOOD-TR-002200A

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Kenwood TR-2200 Instruction Manual PDF - Unknown size, submitted by RigReference

: Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TR-2200A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:
