Lafayette HA-63

General characteristics

HAM bands

?

Frequency stability

?

Tuning steps

?

Memories

?

Receiver

RX-range

0.55-1.6 / 1.6-4.8 / 4.8-14.5 / 10.5-30 MHz

Modulations

AM   CW

Sensitivity

1.5 µV

Selectivity

?

Filters

?

Receiver system

7 tubes

IF-frequencies

?

Image rejection

?

Audio output

?

Connections

Antenna

-

Impedance

?

Other

-

Electrical

Power requirements

Mains

Current drain RX

?

TX

-

Physical

Dimensions (w×h×d)

330 × 200 × 255 mm (12.99 × 7.87 × 10.04 in)

Weight

8.60 kg (19.0 lbs)

Form factor

Base Station

Manufactured

Between 1963 and 1966

Other features

Usage

Amateur / Ham radio operators

Features + options

Electrical bandspread on 80, 40, 20 ,15 and 10m bands
Slide rule display
AVC-MVC selector
ANL
BFO
Antenna trimmer

Accessories

-

RigReference ID

3542

MPN

LAFAYETTE-HA-000063
