Ten-Tec 1315

Mobile Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Find Ten-Tec 1315 rigs and spare parts on eBay

Find the Ten-Tec 1315 on Amazon
We receive a small fee if you buy through these links, which helps support this site. Thank you!

4 Models of the 1300 series QRP transceiver kit are available: Model 1320 for 20 meters, model 1330 for 30 meters, model 1340 for 40 meters, and model 1380 for 80 meters. Each kit is priced at USD 119.00 (2009).

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: ?
Memories: ?

Receiver

RX-range: 15 m
Modulations: -
Sensitivity: 0.25µV typical for 10 dB S/N
Selectivity: 4 pole crystal ladder filter (1 kHz nominal bandwidth)
Filters: ?
Receiver system: Single conversion superhet, JFET mixer
IF-frequencies: ?
Image rejection: ?
Audio output: 300 mW @ 4 ohms. Built-in 4" speaker in top of cabinet.

Transmitter

TX-range: 15 m
Modulations: -
RF-output: 3W

Connections

Antenna: SO-239
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 12-14V DC
Current drain RX: 35-80mA
TX: 800mA

Physical

Dimensions (w×h×d): 152 × 70 × 152 mm (5.98 × 2.76 × 5.98 in)
Weight: 1.02 kg (2.3 lbs)
Form factor: Mobile
Manufactured: Between 19xx and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 4147
MPN: TEN-TEC-001315
