Digital readout

General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
≤ 100 Hz in any 30 minute period
Tuning steps
Continuous
Memories
11 channels in 1 bank(s)

Receiver

RX-range
10-160 m + CB and WWV/JJY
Modulations
AM   CW   SSB
Sensitivity
0.25 µV (10 dB S/N)
Selectivity
AM
6 kHz (-6 dB), 12 kHz (-60 dB)
SSB
2.4 kHz (-6 dB)
4 kHz (-60 dB)
CW/FSK
600 Hz (-6 dB)
1.2 kHz (-60 dB)
Filters
?
Receiver system
Single conversion superheterodyne
IF-frequencies
1st: 9 MHz
Image rejection
≥ 60 dB (15-160 m), ≥ 50 dB (10 m)
Audio output
3 W at 10% distortion / 4 ohm

Transmitter

TX-range
10-160 m
Modulations
AM   CW   SSB
RF-output
SSB/CW: 100 W, AM: 25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.5V DC
Current drain RX
Max 1.1 A
TX
Max 21 A

Physical

Dimensions (w×h×d)
280 × 125 × 370 mm (11.02 × 4.92 × 14.57 in)
Weight
9.00 kg (19.9 lbs)
Form factor
Base Station
Manufactured
Between 197x and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Optional XTAL controlled memories
Accessories
-
RigReference ID
4284
MPN
YAESU-FT-000301D

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
FT 301 / A / D / S / AD / SD 13 years ago by foxfire55
YAESU FT 301 / 301D / 301S / 301SD 13 years ago by foxfire55

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-301D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-301D is around:

  • USD 13.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1976 USD 1000.00 New / Mint foxfire55
