Ranges: .15-.4, 1.6-4.8, 4.8-14.5, 10.5-30 and 48-54 MHz. ¹ Note the gap of the MW band from .4-1.6 MHz and the gap from 30 to 48 MHz. Bandspread ranges: 3.5-3.7, 3.7-3.94, 7-7.17, 7.17-7.35, 14-14.4, 21-21.5 and 28-30 MHz. A separate SO-239 antenna jack is provided for 6 meters. Requires a speaker. Lafayette #99A2523WX. The calibrator crystal is optional.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 6m 10m
- Frequency stability
- ?
- Tuning steps
- Continuous
- Memories
- 6 channels in 1 bank(s)
Receiver
- RX-range
- 150 kHz- 54 MHz
- Modulations
- AM CW SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- Single conversion
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- requires external speaker
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- Mains
- Current drain RX
- ?
- TX
- -
Physical
- Dimensions (w×h×d)
- 432 × 191 × 254 mm (17.01 × 7.52 × 10.00 in)
- Weight
- 10.40 kg (22.9 lbs)
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- ¼" Head. Jack • S-Meter • Dial Lamp • Antenna Trimmer • RF Gain • ANL • Bandspread • Calibrator 100 kHz² • Mute • MVC/AVC • Standby • Speaker Terminals • BFO • Q-Multiplier • Line Out 500 ohms
- Accessories
- -
- RigReference ID
- 4479
- MPN
- LAFAYETTE-HA-000225
