Model / FCC no. 1009001
General characteristics
- HAM bands
- 11m (CB)
- Frequency stability
- ?
- Tuning steps
- Channelized
- Memories
- 40 channels in 1 bank(s)
Receiver
- RX-range
- 26.965-27.405 MHz
- Modulations
- AM USB LSB
- Sensitivity
- AM: 0.75 µV (10 dB (S+N)/N)
SSB: 0.25 µV (10 dB (S+N)/N) - Selectivity
- 4.2 kHz (-6 dB), 7 kHz (-60 dB)
- Filters
- ?
- Receiver system
- Single conversion superheterodyne
- IF-frequencies
- 7.8 MHz
- Image rejection
- ≥ 70 dB
- Audio output
- 3 W at 10% distortion / 8 ohms
Transmitter
- TX-range
- 26.965-27.405 MHz
- Modulations
- AM USB LSB
- RF-output
- AM: 4 W, SSB: 12 W (PEP)
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 11.7-15.9 V DC
- Current drain RX
- 2 A
- TX
- 3 A max
Physical
- Dimensions (w×h×d)
- 232 × 65 × 275 mm (9.13 × 2.56 × 10.83 in)
- Weight
- 3.55 kg (7.8 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1978 and 1979 in Taiwan
Other features
- Usage
- Citizen Band (27Mc)
- Features + options
- PA
ANL
Noise Blanker
RF & Mic gain
SWR-meter
Tone
Dimmer
Scanning - Accessories
- -
- RigReference ID
- 4880
- MPN
- PRESIDENT-ADAMS
Manuals, diagrams and brochures
- President Adams Owner's Manual PDF - 3.17 MB, submitted by RigReference
- President Adams Schematic Diagram PDF - 1.78 MB, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used President Adams. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
These estimates are based on the following prices:
