RadioShack / Realistic Pro-405

Desktop VHF/UHF Scanner / receiver

Specs Manuals (0) Reviews (1) Prices (0) Compare

Find RadioShack / Realistic Pro-405 rigs and spare parts on eBay

Find the RadioShack / Realistic Pro-405 on Amazon

The RadioShack / Realistic Pro-405 is a desktop VHF/UHF scanner / receiver. It covers 29-54 / 87.3-174 / 380-512 MHz (with gaps) and features a double conversion superheterodyne receiver system with IF frequencies of 1st: 10.7 MHz and 2nd: 455 kHz. It has an image rejection of 70 dB, 20 memory banks and 200 memory channels. The audio output is 0.7 W @ 10% THD. It also features NOAA Wx alert and FM broadcast receive. Dimensions are 60 × 210 × 175 mm.

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: ?
Memories: 200 channels in 20 bank(s) @ 80 channels/second

Receiver

RX-range: 29-54 / 87.3-174 / 380-512 MHz (with gaps)
Modulations: FM
Sensitivity: 29-54 MHz 0.5 µV
87.3-107.9 MHz ((S+N)/N 30 dB) 1.0 µV
108-136.99166 MHz 1.0 µV
137-174 MHz 0.5 µV
380-512 MHz 0.7 µV
(S+N)/N 20 dB unless noted
Selectivity: +/-8 kHz -6 dB
+/-17 kHz -50 dB
Filters: ?
Receiver system: Double conversion superheterodyne
IF-frequencies: 1st: 10.7 MHz
2nd: 455 kHz
Image rejection: 70 dB
Audio output: 0.7 W @ 10% THD

Connections

Antenna: BNC
Impedance: 50Ω
Other: -

Electrical

Power requirements: 9V DC
Current drain RX: 8 W
TX: -

Physical

Dimensions (w×h×d): 210 × 60 × 175 mm (8.27 × 2.36 × 6.89 in)
Weight: 700 gr (1.5 lbs)
Form factor: Base Station
Manufactured: Between 2008 and 20xx

Other features

Usage: Amateur / Ham radio operators
Features + options: NOAA Wx alert
FM broadcast receive
No Mil-Air and no Trunking
Accessories: -
RigReference ID: 5027
MPN: RADIOSHACK-/-REALISTIC-PRO-000405
